MGK-335 Ratio For ()

Description

Brand: Motive Gear
F350 1999-2016 D60F/D80R 4.10
UPC: 00698231666067
App/Model: Dana 60 Reverse|Dana 80
Cover Bolt Quantity: 10
Differential Carrier Break: 4.10 Ratio and Lower Front (D60-410F)|4.10 Ratio and Higher Rear (D80-410)
Differential Model: Dana 60 Reverse|Dana 80
Gear Ratio: 4.10
Pinion Gear Tooth Quantity: 10
Pinion Shaft Diameter: 1.626 Front (D60-410F)|2 Rear (D80-410) Inch
Pinion Spline Count: 29 Front (D60-410F)|37 Rear (D80-410)
Prop 65 Yes/No: No
Ring Gear Bolt Quantity: 12
Ring Gear Material: 8620 Steel
Ring Gear Outside Diameter: 9.75 Front (D60-410F)|11.25 Rear (D80-410) Inch
Ring Gear Rotation: Reverse Front (D60-410F)|Standard Rear (D80-410)
Ring Gear Tooth Quantity: 41
Taxonomy A: LD Differential
Taxonomy B: Ring and Pinion Gear Packages
Taxonomy C: Front and Rear
Taxonomy D: 4.10
For Dana 60 and Dana 80 – Ring and Pinions Including Timken Bearing Kits; 4.10 Ratio; Requires 4.10 and Lower Front Carrier; Requires 4.10 and Lower Rear Carrier

Installation Instructions
Installation Instructions
Installation Instructions
Installation Instructions
Installation Instructions
Installation Instructions

Warranty Period: 1 Year or 50,000 Miles

Applications:

• 1999-2016 Ford F-350 Super Duty
• 1999-2004 Ford F-450 Super Duty

MGK-335 Cross Reference
